M.O.R.P.H. / COMPLETE MANUAL
Install it once.Understand every control.
Start with the correct MT5 Data Folder, activate secure access, then learn every workspace—from order planning to chart mapping.
THE STANDARD BEHIND THE SYSTEM
M.O.R.P.H.Multi-purpose • Optimized • Responsive • Practical • Honed
Five product principles that define how every M.O.R.P.H. tool is designed: versatile in purpose, efficient in operation, responsive in use, practical in workflow, and continuously refined.
01 / FILE PLACEMENT
Place every EX5 file in the correct MT5 folder.
In MT5, select File → Open Data Folder. Always open the folder from the terminal because one computer can contain several independent MT5 Data Folders.
COMPILED FILEDESTINATIONPURPOSE
M.O.R.P.H. Trading Assistant MASTER.ex5MQL5\ExpertsPRO EA with Scalping and Swing modes.M.O.R.P.H. Scalping Assistant.ex5 / M.O.R.P.H. Swing Assistant.ex5MQL5\ExpertsStandalone assistants are installed only when included in the member product access.M.O.R.P.H. Mapping Visualizer MASTER.ex5MQL5\IndicatorsRange, structure, Fibonacci, area, and EMA visualization.M.O.R.P.H. Base Candle Marker MASTER.ex5MQL5\IndicatorsLive and historical base-candle classification.M.O.R.P.H. Free Movement.ex5MQL5\ScriptsAdds more freedom when positioning the chart.M.O.R.P.H. Reset Chart.ex5MQL5\ScriptsReturns the visual workspace to a clean state.LICENSED PRODUCTInstall and attach only the M.O.R.P.H. assistant product assigned to your member access.
- Open the destination folder.Use MQL5\Experts, MQL5\Indicators, or MQL5\Scripts according to the table.
- Copy the compiled files.End users only need the EX5 release files; MQ5 source files are not required.
- Refresh Navigator.Press Ctrl+N, right-click inside Navigator, and choose Refresh. Restart MT5 if a file is still missing.
02 / MT5 PERMISSIONS
Allow trading, licensing, and the Forex Factory feed.
Open Tools → Options → Expert Advisors, then configure these permissions before attaching the EA. Both URLs below must be listed separately.
VERIFY BOTH URLSIf the license URL is missing, login can stop at ‘Contacting secure server’. If the Forex Factory domain is missing, the NEWS panel shows NO FEED even though the EA can still reach SYSTEM | READY.
03 / SECURE ACTIVATION
Register once, then use your private login.
- 01
Attach the licensed EA
Drag your licensed M.O.R.P.H. assistant from Navigator → Expert Advisors onto one chart.
- 02
FIRST-TIME SETUP
Enter the username and one-time registration code supplied by the owner.
- 03
Create your password
Create a private password and store it safely. Never send it to another person.
- 04
Sign in
Use your username and password. Remember Username stores only the username.
- 05
Confirm readiness
Wait for SYSTEM | READY, then confirm that every licensed module is available.
CHANGE TIMEFRAMEThe active session is preserved and the interface rebuilds automatically.
REMOVE + REATTACH EAThis is a new attachment and requires login again.
LOG OUTClick LOG OUT, then CONFIRM LOG OUT within five seconds.
04 / TRADING ASSISTANT
One EA. Two complete trading workspaces.
Trading Assistant PRO contains both Scalping and Swing workflows. Scalping Assistant and Swing Assistant are dedicated standalone products with workflow-specific interfaces.
INPUT PANEL
Build lot, price, protection, target, and order settings.
ASSISTANT
Monitor tickets and apply position-management actions.
TRADE HISTORY
Review closed trades, results, and account performance.
CONTROL PANEL
Control zones, pivots, overlays, lookback, and mapping.
05 / SCALPING MODE
Plan layered entries and manage every ticket precisely.
Scalping mode converts the active Ceiling–Floor range into layered pending orders. Complete the three Input Panel sections from top to bottom, verify the live estimate, then execute.
LOT MANAGEMENT
Defines how exposure is calculated and distributed.
- FIXED
- Uses the lot size entered by the user.
- RISK %
- Calculates lot size from an account-risk percentage and the effective protection boundary.
- RISK $
- Calculates lot size from a fixed money-risk amount.
- TOLERANCE
- Adds the Scalping tolerance option for layer planning.
- LIVE ESTIMATE
- Shows lot per layer, total lot, ATR, spread, and minimum CutLoss risk before execution.
ENTRY MANAGEMENT
Builds the PAC range and layer distribution.
- CEILING / FLOOR
- Sets the upper and lower boundaries used to construct the plan.
- MULTI / LAYER
- Controls the layer multiplier sequence and number of planned layers.
- CUTLOSS %
- Sets the candle-close protection threshold for the Scalping basket.
- CL ON / OFF
- When ON, candle-close CutLoss is the primary guard; the broker hard SL remains the emergency stop.
- MAX RISK $ · AUTO / MANUAL
- AUTO places hard SL from the configured area-width multiplier and follows area changes. Enter a positive USD value for MANUAL: the EA recalculates hard-SL price from lot, layers, multipliers, tick value, and spread, then preserves that per-side target when the area changes. Enter zero or click the mode control to return to AUTO.
MARKET ORDER
Places or removes the prepared order set.
- BUY LIMIT
- Places the prepared buy-side layer set.
- BUY & SELL
- Places both prepared directions after verification.
- SELL LIMIT
- Places the prepared sell-side layer set.
- DELETE BUY / ALL / SELL
- Cancels the corresponding pending-order group.
- SHOW / HIDE PAC LINES
- Shows or hides planning lines without changing order logic.
Scalping Assistant controls
Ticket list and filters
Shows up to five tickets per page with setup, source timeframe, side, layer, status, floating P/L, or pending entry. Use ALL, RUNNING, and PENDING.
Exact-ticket actions
Select a row to MODIFY SL or MODIFY TP. X closes or cancels only that ticket; OPEN CHART opens its source chart.
CLOSE ALL
Emergency basket action for the active Scalping set. Verify the visible filter and tickets first.
SAFETY TP
BEP+ solves a basket target from actual fills, lot sizes, swap, and conservative recent round-trip commission. PLUS $ is real money; cent accounts are converted internally. TP PROX and TP OPP are one-shot target moves.
06 / SWING MODE
Build a zone-based plan with correct protection and RR.
Swing mode separates candle-close CutLoss from the broker hard SL. This distinction changes the risk distance used to calculate every RR target.
CUTLOSS ONRR distance = Entry → exact distal CutLoss. Hard SL stays outside distal ± buffer as emergency protection, so TP is shorter.
CUTLOSS OFFRR distance = Entry → hard SL outside distal ± buffer. The wider risk distance produces a longer TP.
LOT MANAGEMENT
Defines position size from the selected risk model.
- FIXED
- Uses the entered fixed lot size.
- RISK %
- Sizes the position from account-risk percentage and the active risk boundary.
- RISK $
- Sizes the position from a fixed money-risk amount.
- TOLERANCE
- Shown for interface consistency but unavailable in Swing mode.
ENTRY MANAGEMENT
Defines entry, protection, and target behavior.
- SINGLE / MULTIPLE RR
- Selects one target or an RR ladder with TP1 through TP5.
- ENTRY
- Defaults to the zone proximal reference and can be adjusted before execution.
- MANUAL SL
- The broker hard stop, normally outside distal by the selected buffer.
- BUFFER ATR / PIPS
- ATR uses a percentage of adaptive anchor-timeframe ATR(14), default 10%. PIPS uses a fixed distance, default 5; zero removes the buffer.
- CUTLOSS
- Uses exact distal and executes after candle close. It is the primary exit when ON; hard SL remains the emergency guard.
- MANUAL TP / RR
- SINGLE accepts a manual target or calculated RR. MULTIPLE RR builds the selected target ladder.
- GUARD / MAX TP
- MAX TP selects one to five targets. Guard OFF, TP2, or TP3 protects remaining positions after the chosen target.
- SHOW / HIDE LINES
- Shows or hides planning lines without changing the stored plan.
MARKET ORDER
Executes the verified Swing plan.
- BUY NOW / SELL NOW
- Opens a market position using the active plan.
- PENDING BUY / SELL
- Places a pending order using the prepared Swing levels.
Swing Assistant controls
Ticket list and filters
Shows up to five tickets per page with selection, status, levels, and pagination. Use ALL, RUNNING, PENDING, or OPEN CHART.
Close and modify
Use row X for one ticket, or CLOSE ALL, CLOSE PROFIT, and CLOSE LOSS for grouped actions. Selected tickets support MODIFY SL and MODIFY TP.
Single-position protection
Running SINGLE tickets support MOVE TO BEP, BEP OFFSET, TRAILING STOP, and TRAIL OFFSET PIPS. Pending tickets can be modified, but BEP and trailing start only after running.
MULTIPLE RR
Keeps compact SL/TP controls while preserving the target ladder and Guard rules defined in Input Panel.
07 / LIVE OPERATIONS
Read the live workspace before taking action.
The Assistant, Trade History, NEWS, SYSTEM, and candle countdown provide different layers of information. They remain synchronized with the current chart, active workflow, and licensed session.
Assistant panel anatomy
LIVE HEADER
Identifies the active workspace and current market context.
- MODE / SYMBOL / TF
- Shows SCALPING ASSISTANT or SWING ASSISTANT together with the symbol and source timeframe used by the active chart.
- COUNTDOWN
- Shows the remaining MM:SS until the current candle closes. The same timer is also drawn beside the live candle and updates from the latest real symbol tick.
- FLOATING P/L
- Displays the floating result for the Assistant's active scope. It is an information display, not a prediction or an automatic close command.
TICKET MANAGER
Separates monitoring, selection, and execution actions.
- ALL / RUNNING / PENDING
- Filters the visible list without changing the underlying positions or orders. Each row shows its setup, side, layer or RR target, entry/SL/TP, status, and available action.
- PAGES / 5 ROWS
- The list displays up to five tickets per page. Use the arrow controls and page indicator to inspect the rest of the active set.
- OPEN CHART
- Opens the source symbol and timeframe of the selected ticket so that the originating setup can be reviewed directly.
- ROW X / SELECTION
- The X action closes or cancels only the exact row. Selecting a row exposes the applicable MODIFY SL and MODIFY TP controls.
- GROUP ACTIONS
- Scalping provides CLOSE ALL for its basket. Swing additionally provides CLOSE PROFIT and CLOSE LOSS to act on the corresponding running group.
Scalping Safety TP
Target a real basket result.
Enter PLUS $ and press BEP+. The EA solves one basket target from actual running fills and lot sizes, current swap, and a conservative estimate of recent round-trip commission. PLUS $ is real money; USC cent accounts are converted internally. The preview uses running positions only, while the one-shot action moves eligible same-side running positions and legal remaining pending orders in the active setup and timeframe.
Return the active batch to its own proximal.
Pressing TP PROX once moves TP for matching running positions and pending orders from the active Floor–Ceiling batch and current timeframe to that side's proximal. Other setups and timeframes are not modified. If only one side is running, the action is restricted to that side.
Use the nearest visible opposing proximal.
TP OPP searches between live price and the canonical TP for the nearest visible opposing M.O.R.P.H. zone: supply proximal for BUY, demand proximal for SELL. Its preview estimates the running basket result and labels it SAFE, PLUS, or MINUS. Pressing the button performs a one-shot TP move for the eligible same-side active batch; it remains unavailable when no valid opposing zone exists.
ONE-SHOT ACTIONSBEP+, TP PROX, and TP OPP modify TP only when pressed; they do not arm a recurring watcher. They preserve SL and CutLoss. A BEP+ target already passed by live price is displayed as PASSED and does not force a market close.
TRADE HISTORY
CONTROLWHAT IT SHOWS
ALL / SCALPING / SWINGFilters closed records by workflow. It does not alter open positions or pending orders.
PERIOD / DAYSSelects the review window used to calculate and display closed-trade records.
NET / REAL-TIME BALANCENET summarizes the selected closed results. Real-time balance provides the current account reference beside that history.
RECORD COLUMNSEach row identifies pair and timeframe, side, realized result, and close reason such as TP, SL, CutLoss, or a manual action when available.
PAGINATIONUse previous/next and the visible row-count controls to move through longer histories without covering the chart.
NEWS, SYSTEM, and countdown
FOREX FACTORY NEWS
Forex Factory is the sole authority for impact classification. The panel shows only remaining events whose currency exactly matches USD, whose impact is exactly High, and whose time is still inside the current WIB calendar day. The compact panel shows the count and nearest time; expand it to read the nearest event title. NO FEED indicates that the host could not be reached or was not allowed in MT5 WebRequest.
PRE-NEWS ALERT
By default, the EA warns 30 minutes before the nearest eligible High-impact USD event through an MT5 popup and embedded sound. Mobile push is optional and requires MT5 Notifications to be configured first. The alert is a risk reminder and does not automatically pause or close trades.
SYSTEM + COUNTDOWN
SYSTEM reports the startup stages—NEWS, PREP, ZONES, UI, and WAIT UI—before READY. The candle countdown displays only the remaining MM:SS to the next bar and follows the latest real tick; it is not an entry signal. A temporarily unchanged timer can occur when the symbol has no incoming tick.
09 / MAPPING VISUALIZER
Turn a manual range into a complete visual map.
Set Floor and Ceiling first. The indicator then gives the EA and chart a shared range, structure chain, Fibonacci context, area position, and trend references.
Set the range
Enter or drag Floor and Ceiling. Setting both to zero clears mapping. LEFT and RIGHT extend the range backward and forward; defaults are 20 and 30 bars.
Read area position
EQ marks equilibrium. The range is divided into BUY ZONE, LOWER MID (25–50%), UPPER MID (50–75%), and SELL ZONE. Status reports BUY, SELL, MID, EQ, or NOT SET.
Choose overlays
AREA shows range quarters. MS draws confirmed structure with solid lines and developing structure with dashed lines. FIBO uses the same swing chain and marks 0.382 and 0.618.
Add trend context
E1, E2, E3, and E4 are independent EMA slots. Their editable periods default to 20, 50, 100, and 200, so you can display any combination of one to four EMA lines.
CONTROLBEHAVIOR
MS / 500Toggles structure. Visible depth defaults to 500 bars; analysis supports up to 5,000.
FIBO / 3Toggles Fibonacci and chooses 1–50 swing sets. Set 1 is developing; older sets are confirmed.
E1 / E2 / E3 / E4Each button toggles one EMA slot; the adjacent field sets its period. Defaults are 20/50/100/200 and all choices persist per chart.
AREA ON / OFFShows or hides mapped areas without removing Floor and Ceiling.
CONNECTED OR STANDALONEMapping Visualizer can follow EA-managed controls or run independently. Its bottom-right minimized state persists across timeframe changes.
10 / BASE CANDLE MARKER
See every live base first, then filter older structure.
Base Candle Marker recolors qualifying base candles in yellow. Its recent-window rule is intentionally different from its historical filter.
Mark every qualifying base.
Shifts 0 through 20 use only Base Body calibration. Every qualifying base is marked regardless of RBR, DBD, RBD, or DBR formation and regardless of Pivot state.
Apply the active Pivot filter.
From shift 21 onward, Pivot OFF keeps RBR and DBD bases. Pivot ON includes RBR, DBD, RBD, and DBR bases.
SETTINGPURPOSE
BASE BODY %Sets the body calibration threshold used to classify a base candle. Default: 50%.
HISTORY DEPTHControls the historical scan, up to 5,000 bars.
EA ON/OFF + PIVOTLive synchronization polls EA controls every second. Changes update automatically; no manual OFF/ON refresh is required.
STANDALONE MODEWithout Trading Assistant authority, the indicator uses its own fallback settings.
11 / KEYBOARD SHORTCUTS
Operate faster without sacrificing deliberate control.
Keyboard control is OFF on a fresh attachment. Press the period key or Numpad Decimal to switch it ON or OFF. The KEY ON/OFF indicator confirms the current state; clicking that indicator opens the built-in shortcut table.
WORKSPACE
- . / NUMPAD DECIMAL
- Keyboard shortcuts ON/OFF
- ,
- Switch Scalping / Swing
- `
- Show / hide workflow lines
- TAB
- Toggle zone visuals
PANELS
- Q
- Input Panel
- W
- Assistant
- E
- Trade History
- R
- Control Panel
- T
- Mapping Visualizer
VISUAL MODULES
- F
- Fibonacci
- M
- Market Structure
- V
- Base Marker ON/OFF
- P
- Pivot
CTRL + Numpad trade map
CTRL + NUM 7SELL PENDING
CTRL + NUM 8BUY & SELL PENDINGSCALPING ONLY
CTRL + NUM 9BUY PENDING
CTRL + NUM 4SELL NOW
CTRL + NUM 5RESERVED BY MT5
CTRL + NUM 6BUY NOW
CTRL + NUM 1DELETE SELL PENDING
CTRL + NUM 2DELETE ALL PENDING
CTRL + NUM 3DELETE BUY PENDING
CTRL + DELETECloses the active M.O.R.P.H. scope: the current-chart Swing set or the Scalping position basket. Verify the active mode before using it.
KEYBOARD SAFETYNum Lock must be ON. Swing uses the same map, but CTRL + NUM 8 does not place an order. Shortcuts are ignored while an input field is selected, and key-repeat protection prevents repeated actions from a held key.
12 / UTILITIES
Run additional tools from Navigator → Scripts.
More chart positioning freedom
Drag the script onto the chart being analyzed. It operates separately from EA trading authority.
Return to a clean visual workspace
Check active trades first, then run Reset Chart. It is not a logout or Close Position command.
